MAKK2520H1R0M

MAKK2520H1R0M

Manufacturer Part MAKK2520H1R0M
Manufacturer Taiyo Yuden
Description FIXED IND 1UH 3A 53 MOHM SMD
Category Inductors, Coils, Chokes
RoHS Lead free / RoHS Compliant
Warranty 365 days
Datasheet -
GB-T-27922
ISO-9001-2015
ISO-13485
ISO-14001
ISO-28000-2007
ISO-45001-2018
Product Attributes
Type Description
Product Status:Active
Type:Drum Core, Wirewound
Material - Core:Metal
Inductance:1 µH
Tolerance:±20%
Current Rating (Amps):3 A
Current - Saturation (Isat):4.2A
Shielding:Shielded
DC Resistance (DCR):53mOhm Max
Q @ Freq:-
Frequency - Self Resonant:-
Ratings:-
Operating Temperature:-40°C ~ 125°C
Inductance Frequency - Test:2 MHz
Features:-
Mounting Type:Surface Mount
Package / Case:1008 (2520 Metric)
Supplier Device Package:1008 (2520 Metric)
Size / Dimension:0.098" L x 0.079" W (2.50mm x 2.00mm)
Height - Seated (Max):0.039" (1.00mm)
