P0396NLT
| Manufacturer Part | P0396NLT |
|---|---|
| Manufacturer | Pulse Electronics Power |
| Description | INDUCT ARRAY 2 COIL 3.5UH SMD |
| Category | Inductors, Coils, Chokes |
| RoHS | Lead free / RoHS Compliant |
| Warranty | 365 days |
| Datasheet | - |
Product Attributes
| Type | Description |
|---|---|
| Product Status: | Active |
| Number of Coils: | 2 |
| Inductance - Connected In Parallel: | 3.5 µH |
| Inductance - Connected In Series: | 14 µH |
| Tolerance: | ±20% |
| Current Rating - Parallel: | 11.2 A |
| Current Rating - Series: | 5.6 A |
| Current Saturation - Parallel: | - |
| Current Saturation - Series: | - |
| DC Resistance (DCR) - Parallel: | 6.54mOhm |
| DC Resistance (DCR) - Series: | 26.2mOhm |
| Shielding: | Unshielded |
| Ratings: | - |
| Operating Temperature: | -40°C ~ 130°C |
| Mounting Type: | Surface Mount |
| Package / Case: | Nonstandard |
| Size / Dimension: | 0.715" L x 0.590" W (18.16mm x 14.99mm) |
| Height: | 0.310" (7.87mm) |
